. SMT and integrative design
. ABS waterproof enclosure
. Membrance touch keys
. User interface language:English
. Simultaneous display of multiparameters
. Automatic or manual temperature compensation
. Combination glass ph electrode---faster response
. BNC port
. Several calibration methods available
. CPU intelligent design
. 4 individually password protected
. Datalog with time and date stamp
. Intelligent measurement, Auto judge as calibration is stable---ease operation
. Universal power supply for worldwide operation (100~240)V
|
Display |
192 × 64 lattice LCD |
|
Measurement Range |
(0.00~14.00)pH |
|
Resolution |
0.01 pH |
|
Accuracy |
±0.02 pH |
|
Input Impedance |
≥1×1012W |
|
Response Time |
90% within 1 minutes |
|
Temperature Sensor |
Pt1000 |
|
Temperature Range |
(0.0~99.9)oC |
|
Temperature Accuracy |
±0.5oC |
|
Temperature Resolution |
0.1 oC |
|
Temperature Compensation |
(0.1~60.0)oC (auto or manual) |
|
Sample Temperature |
(5~60)oC |
|
Ambient Temperature |
(5~45)oC |
|
Ambient Humidity |
≤ 90%RH (no condensation) |
|
Storage Temperature |
(-25~55)oC (above 0oC for pH electrode) |
|
Power Supply |
AC (100~240)V,(45~65)Hz |
|
Power Consumption |
≤3W |
|
Overall Dimension(mm) |
268(L) ×197(W) ×58(H) |
|
Net Weight |
3.5kg |
|
Warranty |
18 months (from date of acceptance) |
Meter
1 piece
pH electrode
1 piece
ATC temperature sensor
1 piece
Buffer solution
2 sets
Electrode bracket
1 piece
Plastic Breaker
2pcs
Power wire
1 piece
